Load Cell, Compression Push Pressure Mini Load Cell Spoke Wheel Donut Washer Shaped Ring Force Sensor(200KN)

Product Name:Compression Push Pressure Mini Load Cell Spoke Wheel Donut Washer Shaped Ring Force SensorModel: DYHX-004Sensor type: strain gaugeWork force: 0.5-200KNAccuracy: 0.3% F.SOutput type: Millivolt outputInstallation type: limit installationPower supply voltage: 5 (V)Application areas: Security equipment, hollow design, mainly measuring extrusion force, assembling interference force value detection and controlling other industrial control force value detectionSpecifications: 0.5KN, 1KN, 2KN, 5KN, 10KN (small size), 20KN (small size), 50KN, 100KN, 200KNProduct Technical ParametersRange: 0.5-200KNOutput sensitivity: 1.0+10% mV/VZero point output: ± 2% F.SNonlinear: 0.3% F.SLag: 0.1% F.SRepeatability: 0.1% F.SCreep: (30 minutes): 0.1% F.STemperature sensitivity drift: 0.1% F.S./10 ° CZero temperature drift: 0.1% F.S./10 ° CMaterial: Stainless steelImpedance: 700 ΩInsulation resistance: ≥ 5000M ΩOperating voltage: 5-15VWorking temperature range: -20~80CSafe overload: 120%Extreme overload: 200%Cable size: φ 5x3m

• High Precision Load Cell: Our Compression Push Pressure Mini Load Cell is engineered with a strain gauge sensor, offering an impressive accuracy of 0.3% F.S for precise measurements ranging from 0.5 to 200KN
• Versatile Application Areas: This Load Cell is for various industrial applications including security equipment and measuring extrusion force, making it an essential tool for detecting interference force values in assembly processes
• Robust Design & Construction: Crafted from stainless steel, this Load Cell features a hollow design that ensures durability and reliability even under extreme conditions, with a safe overload capacity of 120%
• Easy Installation & Configuration: Designed for limit installations, our Load Cell operates on a power supply voltage of 5-15V and comes with a cable size of φ 5x3m for straightforward setup and integration into your existing systems
• Exceptional Performance Metrics: With a temperature working range of -20 to 80°C, and low drift characteristics such as zero temperature drift at 0.1% F.S./10 °C, our Load Cell ensures consistent performance and repeatability essential for industrial control force value detection
